Fan performance in recirculation mode
|
Maximum flow rate, normal setting (m³/hr): 110
|
|
Fan performance during exhaust air
|
Min. delivery volume (m³/hour): 170
Maximum flow rate, normal setting (m³/hr): 350
|
|
Filter properties
|
Grease filters are dishwasher safe
Number of metal grease filters: 2
Metal grease filter
|
|
operation
|
Operating method: Button operation
Workplace lighting
Number of lamps: 2
|
Bosch
Bosch DUL63CC50 ed under-cabinet cooker hood 60cm diameter 3-stage metal grease filter
Bosch DUL63CC50 ed under-cabinet cooker hood 60cm diameter 3-stage metal grease filter
Regular price
€275,00
Regular price
€431,00
Sale price
€275,00
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
*** I will personally deliver and install the device for you in the Kaiserslautern and Bad Orb area. ***
EAN 4242002968506
Manufacturer designation DUL63CC50
EAN 4242002968506
Manufacturer designation DUL63CC50
Product description:
|
Colors
|
Case colors: stainless steel
|
|
Case features
|
Increased extraction area: hinged air guide/vapor screen
Length of connecting cable (cm): 145
Weight (kg): 7
Height (cm): 15
Width (cm): 60
Depth (cm): 48.2
|
|
Installation properties
|
Length of connecting cable (cm): 145
Exhaust air connection diameter (mm): 120
Mounting options: Wall mounting/Mounting under upper cabinet
2. Exhaust air connection diameter (mm): 100
|
|
Packaging information
|
Width including packaging (cm): 74.8
Height including packaging (cm): 26.7
Depth including packaging (cm): 65.2
Weight including packaging (kg): 12
|
|
Performance characteristics
|
Backflow preventer
Total motor power (W): 138
Recirculation mode possible with special accessories
Power rating (W): 146
Operating mode: suitable for exhaust and recirculation operation
220-240V 50/60Hz mains connection
Number of ventilation levels: 3
Total lighting power (W): 8
Color temperature (K): 3000
Illuminance (lux): 45
Average annual energy consumption (kWh): 93.6
Number of motors: 1 motor
Energy efficiency class: Energy efficiency class D
Minimum operating noise (dB): 56
Information according to 2010/30/EU
Maximum air volume: 350
Minimum airflow: 170
Fluid dynamics efficiency class: Fluid dynamics efficiency class E
Fluid dynamics efficiency: 8.7
Grease filter efficiency class: Grease filter efficiency class C
Lighting efficiency class: Lighting efficiency class E
Maximum noise level, normal setting: dB: 72
Grease filter efficiency in %: 75.1
Lighting efficiency: 11
Energy efficiency spectrum: Spectrum [A+ to F]
|
